Coating Thickness Meter MEGA-CHECK Basic / Profi / Master

offers the possibility to connect a variety of different probes for the coating thickness measurement on metal

Coating Thickness Meter MEGA-CHECK

The coating thickness gauge

You can connect many specialized probes to the LIST-MAGNETIK MEGA-CHECK, Basic, Profi or Master coating thickness meters. Applications with particularly small openings, thick layers and small measuring points are thus easily possible. Special functions such as the scan measurement for rough surfaces, and the duplex measurement for galvanized, and additionally coated steel complete the performance spectrum.

Trouble-free and precise measurement in coating thickness measurement

The signals are already digitized in the probe (and not in the coating thickness tester) for an absolutely interference-free and precise measurement. This results in very accurate, reproducible measurements.

Wide range of probes for the coating thickness gauge

At LIST-MAGNETIK, you will find a wide range of probes for FE metals (ferrous metals) and NFE metals (non-ferrous metals such as aluminum, brass, copper, bronze and non-magnetic stainless steel) as well as combined probes with automatic recognition of the base material. The combined probe with swivel-mounted head is unique worldwide.

Measurements of layer thicknesses on various layers

The magnet-inductive method allows measurements on all types of paints, varnishes, plastics and galvanic coatings on steel. With the eddy current method, you measure insulating layers (color, varnish, plastic, anodic) on non-ferrous metals.

Multilingual menu display

All coating thickness meter have a large and clear graphic display. The menu is given in German, English, Spanish or Dutch.

Replaceable probe cable for the meter

The probe cable, which can be plugged in on both sides, connects the display unit and the probe and can be easily replaced in the event of a cable break.

High-quality

All LIST-MAGNETIK MEGA-CHECK coating thickness meters are high-quality products "Made in Germany".

Quality assurance through the coating thickness gauge

A coating thickness meter is usually used in the quality assurance of coating processes, for example to determine the paint thickness of a paint job, in the testing of vehicles or steel structures, in fire protection (determination of the layer thickness of steel doors). It is not only a paint thickness gauge, but also gumming, anodizing and galvanic coatings can be measured.


Features of different types of MEGA-CHECK coating thickness gauges

MEGA-CHECK Basic is the standard device for rapid on-site measurement. Flexibly usable by connecting different measuring probes.

MEGA-CHECK Profi provides as an additional service to MEGA-CHECK Basic a data logger and a RS232 interface. The measured values can be statistically evaluated. The documentation of the measurement results with easy operation, is carried out via a connected PC or printer. Three calibration memories are available to store special calibration parts.

MEGA-CHECK Master is a high-end device with easy to use functions for many different applications. In addition to the functions of MEGA-CHECK Profi, the device offers a scan function for the determination of the layer thickness on rough or blasted surfaces as well as the duplex function for the exact determination of the individual layer thicknesses of insulating layers on galvanized steel parts. In the case of continuous measurement of the layer thickness, the analogous representation of the measured value profile proves to be an important support.

Technical data Coating Thickness Meter MEGA-CHECK

Applications: Depending on the selection of the probe measurement of paint, varnish, plastic and galvanic layers on steel, measurement of insulating layers on non-ferrous metals with automatic recognition of the basic material
Standards: ISO 2178, ISO 2360, BS 5411, ASTM
Measuring probe: The measuring range is depending on the probe,
on steel and iron up to 30 mm (30,000 μm),
on NFE metals up to 6 mm (6000 μm).
Minimum area, minimum radius of curvature and calibration value
also depend on the probe.
Accuracy: less than 100 μm ± 1 μm, 100-1000 μm: ± 1%, 1000-2000 μm: ± 3%,> 2000 μm: ± 5%
Resolution: 1-100 μm: 0.1 μm, 100-1000 μm: 1 μm,> 1000 μm: 10 μm
Measuring units: µm and mils
Environment temperature: 0 - 50° C
Display: Graphic display
Multilingual menu navigation: German / English / Spanish / Dutch
Power supply: 3x 1.5 V AA Mignon
Operating time: approx. 60 hours
Dimensions: 200 x 95 x 41 mm
Weight: 265 g (with batteries)

For the MEGA-CHECK Profi and Master devices additionally:

Data logger: 10,000 measured values (In MEGA-CHECK Master divisible into 100 batches)
Statistics: Count / Maximum / Minimum / Average / Standard deviation
Calibration memory: 3 calibration memories for storing individual calibrations /td>
Interface: RS232 interface with USB cable for communication with PC and printer

For the MEGA-CHECK Master device:

Analog display: Analog measured value display with continuous measurement
Scan function: for accurate measurement on rough or blasted surfaces
Duplex function: for the exact determination of the individual layer thickness for measurements of insulating layers on galvanized steel parts (the zinc layer must be > 60 μm)



Scope of supply Coating Thickness Meter MEGA-CHECK:

MEGA-CHECK Basic, without probe, with probe cable, calibration base plates FE + NFE, 2 calibration foils and case, including calibration certificate. The probe must be ordered separately.

MEGA-CHECK Profi, without probe, with probe cable, USB cable, calibration base plates FE + NFE, 2 calibration foils and case, including calibration certificate. The probe must be ordered separately.

MEGA-CHECK Master, without probe, with probe cable, USB cable, calibration base plates FE + NFE, 2 calibration foils and case, including calibration certificate. The probe must be ordered separately.



Measuring probes for Coating Thickness Meters MEGA-CHECK Basic / Profi / Master

Measuring probes for Coating Thickness Meters MEGA-CHECK



Technical probe data Coating Thickness Meter MEGA-CHECK :

Type FE or NFE Model
Measuring range
Smallest Area
Smallest curvature radius
PF-5 FE with spring-loaded guide and prism
0-5000 µm
ø 4 mm
convex: 4 mm
concave: 38 mm
PF-5S FE with spring-loaded guide and prism,
swivel-mounted
0-5000 µm
ø 4 mm
convex: 4 mm
concave: 38 mm
PFN-52D FE + NFE combined Dual function probe with spring-loaded guide and prism
FE 0-5000 µm
NFE 0-2000 µm
ø 8 mm
convex: FE 4 mm,
NFE 6 mm
concave: 38 mm
PFN-52DS FE + NFE combined Dual function probe with spring-loaded guide and prism, swivel-mounted
FE 0-5000 µm
NFE 0-2000 µm
ø 8 mm
convex: FE 4 mm,
NFE 6 mm
concave: 38 mm
PN-6 NFE with spring-loaded guide and prism,
for thick layers
0-6000 µm
ø 8 mm
convex: 6 mm
concave: 38 mm
PF-1S FE with spring-loaded guide and prism for especially small parts and areas, swivel-mounted
0-1000 µm
ø 2 mm
convex: 1 mm
concave: 6 mm
PF-1T FE bar-shaped probe for small spaces
0-1000 µm
ø 2 mm
convex: 2 mm
concave: 16 mm
PF-2T
FE
bar-shaped probe
for small spaces and pipes
0-2000 µm
ø 3 mm
convex: 2 mm
concave: 12 mm
PF-3T
FE
bar-shaped probe
for small spaces and pipes
0-3000 µm
ø 3 mm
convex: 2 mm
concave: 8 mm
PF-6S FE two-pole probe for thick coatings,
swivel-mounted
0-6000 µm
ø 14 mm
convex: 5 mm
concave: 25 mm
PF-30 FE two-pole probe for very thick coatings
0-30000 µm
ø 40 mm
convex: 15 mm
concave: 60 mm
PF-1000 FE with springy sensing probe for small parts and complex areas
0-1000 µm
ø 2 mm
convex: 1 mm
concave: 6 mm



Recommended Optionals:

Thermal Printer TOP-PRINT4

Data Transfer Software TRANSFER

Data Transfer Software TRANSFER-EXCEL

Graphic Evaluation Software STAT-6
