Coating Thickness Meter TOP-CHECK Ferro-1000

TOP-CHECK Ferro-1000 coating thickness gauge with spring-loaded measuring probe for uneven or complex surfaces

Coating Thickness Meter TOP-CHECK Ferro-1000



The TOP-CHECK Ferro-1000 coating thickness gauges from List-Magnetik use a probe that requires a small contact area and low contact force. These compact gages, barely larger than a probe, are ideal for measuring thin coatings on uneven or complex surfaces such as tin cans.

The handy metal housing is splash-proof to IP 64 for trouble-free coating thickness measurements in harsh environments. With a single push button and self-explanatory multi-language menu navigation, the coating thickness gauges are easy to use.

Coating Thickness Meter TOP-CHECK Ferro-1000

Measure insulating coatings on iron and steel

The TOP-CHECK Ferro-1000 is the right choice for iron and steel substrates. The coating thickness gauge uses a magnetic inductive probe to measure coatings of varnish, paint, plastic, rubber, ceramics, galvanic coatings, and electroplated coatings (except nickel) according to ISO 2178.

Manage and Share Measurement Data with Free App

To further process your measurement data, you can pair your coating thickness gauge with Android and iOS mobile devices. Or communicate with a Windows PC. Wireless technology makes it possible. With the Lima Connect app, you can manage projects and assign measurement points to a photo. Measurement results can be statistically evaluated and graphically displayed. The app is free and available for Android, iOS and Windows.

To the side Data transfer application Lima Connect



Technical Data Coating Thickness Meter TOP-CHECK Ferro-1000

Applications: Measurement of paint, varnish, plastic and galvanic coatings on steel (ISO 2178)
Measuring probe: sensing device, springy
Measuring range: on steel and iron: 0-1000 μm
Smallest Area: ø 2 mm
Smallest curvature radius: concave 6 mm, convex 1 mm
Calibration value: 300 µm
Accuracy: less than 100 µm ± 1 µm, > 100 µm: ± 1 %
Resolution: 1-100 µm: 0.1 µm, > 100 µm: 1 µm
Measuring units: μm and mils
Environment temperature: 0 - 50° C
Display: illuminated high contrast graphic OLED display
Menu navigation: English, German, French, Italian, Spanish, Hungarian, Polish, Dutch
Data logger: 4000 measured values flexibly divisible
Statistics: count / maximum / minimum / average / standard deviation
Interface: wireless interface for communication with Android, iOS and Windows
App for Android, iOS, Windows: free of charge via Google Play Store, Apple App Store, List-Magnetik website
Power supply: 1x 1.5 V AA Mignon
Operating time: approx. 50 hours
Dimensions: Ø 28 x 95 mm
Weight: 76 g (with battery)
Download Data sheet TOP-CHECK



Models and scope of delivery Coating Thickness Meter TOP-CHECK Ferro-1000:

Coating Thickness Meter TOP-CHECK Ferro-1000
with calibration base plate FE, 2 calibration foils, spare battery and case, including calibration certificate. The app for Android, iOS and Windows is free. Coating Thickness Meter TOP-CHECK Ferro-1000 To the shop Coating Thickness Meter TOP-CHECK Ferro-1000



Measuring instruments by List-Magnetik - Made in Germany - Quality and durability

Firmware Update TCV2

Firmware Update
TOP-CHECK Dual, Ferro, Ferro-1000, FERRITE-CHECK 140, MP-810A/810T, MP-80V2
Revision 1.207

List-Magnetik GmbH

Click here for Update (.exe)
